מפרט
CPU
AnnapurnaLabs Alpine AL324 ARM® Cortex-A57 quad-core 1.7GHz processor
CPU Architecture
64-bit ARM
Floating Point Unit
yes
Encryption Engine
yes
System Memory
4 GB SODIMM DDR4(1 x 4 GB)
Maximum Memory
16 GB (1 x 16 GB)
Memory Slot
1 x SO-DIMM DDR4
Flash Memory
512 MB (Dual boot OS protection)
Drive Bay
8 x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility
3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives
Hot-swappable
Yes
SSD Cache Acceleration Support
+
Gigabit Ethernet Port (RJ45)
2
10 Gigabit Ethernet Port
2 x 10GbE SFP+
USB 3.2 Gen 1 port
3
Form Factor
Tower
LED Indicators
System Status, LAN, USB, HDD1~8
Buttons
Power, Reset, USB Copy
Dimensions HxWxD
188.2 × 329.3 × 280.8 mm
Weight (Net)
6.38 kg
Operating temperature
0 - 40 °C (32°F - 104°F)
Relative Humidity
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Slot
250W, 100-240V AC, 50/60Hz, 3.5A
Power Consumption: HDD Sleep Mode
27.949 W
Power Consumption: Operating Mode, Typical
50.858 W
Fan
System fan: 2 x 120mm, 12VDC CPU fan: 1 x 60mm
Sound Level
19.6 db(A)
System Warning
Voice prompts or Buzzer
Kensington Security Slot
yes
Max. Number of Concurrent Connections (CIFS)
1500
Jumbo Frame
yes
USB 3.2 Gen 2 port
3
