מפרט
AMD EPYC™ 7232P/7252 8-core/16-thread processor, up to 3.2 GHz
CPU Architecture
64-bit x86
Encryption Engine
AES-NI
System Memory
64 GB RDIMM DDR4 ECC (8 x 8 GB)
Maximum Memory
4 TB (16 x 256 GB)
Memory Slot
16 x RDIMM DDR4
Flash Memory
5GB (Dual boot OS protection)
Drive Bay
24 x 2.5-inch U.2 PCIe NVMe
Drive Compatibility
2.5-inch U.2 NVMe Gen 3 x4 solid state drives
Hot-swappable
SSD Cache Acceleration Support
SR-IOV
2.5 Gigabit Ethernet Port (2.5G/1G/100M)
2 (2.5G/1G/100M/10M)
25 Gigabit Ethernet Port
2 x 25GbE SFP28 SmartNIC port
Wake on LAN (WOL)
Only the 2.5GbE port
Jumbo Frame
PCIe Slot
Slot 1: PCIe Gen4 x4
Slot 2: PCIe Gen4 x8 or x4
Slot 3: PCIe Gen4 x4
Slot 4: PCIe Gen4 x8
Slot 5: PCIe Gen4 x16 or x8
USB 3.2 Gen 1 port
Form Factor
Rackmount
LED Indicators
HDD, Status, 10 GbE, LAN, storage expansion port status
LCD Display/ Button
Buttons
Power, Reset
Dimensions
88.3 × 480.97 × 510.23 mm
Weight
15.2 kg
Operating Temperature
0 - 40 °C
Storage Temperature
-20 - 70°C
Relative Humidity
5-95% RH non-condensing, wet bulb: 27˚C
Power Supply Unit
1100W PSU(x2), 100-240Vac,
Max Wattage:
1100W@200-240Vac
850W@100-240Vac
4 x 60mm, 12VDC
System Warning
Buzzer
Max. Number of Concurrent Connections (CIFS) - with Max. Memory
10,000
Power Consumption: Operating Mode, Typical
277.64 W
