מפרט
Dimensions (L x W x H)
162.74 mm length × 1-slot width × Low-profile (The dimension is based on PCBA size × not including the bracket) mm
Controller
Intel Ethernet Controller E810-CAM2
Number of Ports
2 x QSFP28 ports
Connector
QSFP28
PCIe and Lanes
PCIe 4.0 x16 (Compatible to PCIe 3.0 x16)
Transmission Rates
100Gbps
IEEE Standards
IEEE Std 802.3-2018 | IEEE Std 802.3cd-2018 | IEEE P802.3bd-2011 | IEEE Std 802.1D-2004 | IEEE Std 802.1Q-2011
Bracket
Low-profile bracket pre-installed; full-height and specialized (for selected QNAP NAS) brackets are bundled
SR-IOV Support
yes
iSER Support
yes
NVGRE, VXLAN, Geneve Support
yes
1K ingress and egress QoS levels
On-chip QoS
Supported NAS operating systems
QTS / QuTS hero (recommend an upgrade to the latest version)；Windows (Driver Required)；Linux (Driver Required)
Supported QNAP NAS
Models with PCIe slot(s) (1 free slot required)
Support Ubuntu Commercial Linux Distribution
Ubuntu 18.04/20.04
Support Windows Server
Windows Server 2019
Port and Cable
QSFP28 DAC cable or OPTIC transceiver
Package Contents
1 x Network card; 1 x QIG; 2 x Brackets
Standard Warranty
3 years
