מפרט
CPU
AMD Ryzen™ Embedded V1500B quad-core 2.2 GHz processor
CPU Architecture
64-bit x86
Floating Point Unit
yes
Encryption Engine
yes
System Memory
16 GB UDIMM DDR4 (1 x 16 GB)
Maximum Memory
32 GB (2 x 16 GB)
Memory Slot
2 x Long-DIMM DDR4
Flash Memory
5GB (Dual boot OS protection)
Drive Bay
16 x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility
3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives
Hot-swappable
Yes
SSD Cache Acceleration Support
+
Gigabit Ethernet Port (RJ45)
2
10 Gigabit Ethernet Port
Optional via a network adapter
USB 3.2 Gen 1 port
1
Form Factor
3U Rackmount
LED Indicators
HDD 1-16, Status, LAN, USB, Power
Buttons
Power, Reset
Dimensions HxWxD
132 × 482 × 425 mm
Weight (Net)
12 kg
Operating temperature
0 - 40 °C (32°F - 104°F)
Relative Humidity
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Slot
550W (x2), 100-240V AC, 50-60Hz, 7-3.5A
Power Consumption: HDD Sleep Mode
47.75 W
Power Consumption: Operating Mode, Typical
97.34 W
Fan
3 x 80mm, 12VDC
Sound Level
23~47.9 db(A)
System Warning
Buzzer
Kensington Security Slot
-
Max. Number of Concurrent Connections (CIFS)
1200
Jumbo Frame
yes
USB 3.2 Gen 2 port
3
